ISDB-T Digital TV Tuner with Japanese B-CAS & 2-CH Diversity Supported
Geniatech S280 is a portable TV stick that supports the Japanese B-CAS standard and can watch ISDB-T digital TV on any Android smart device, in line with the ISDB-T standard, designed with sony Tuner & demod chips, low power consumption and good compatibility
- Sony Tuner and demod inside
- High receiver sensitivity
- USB2.0 interface to Android device
- Low power comsuption
- Support watching b-cas encrypted program
- Support 2-way diversity function(MRC)
Specification
| Input Terminal | 75 Ohm PAL Connector |
| Receive Frequency | TV 177.143Mhz ~ 803.143 MHz |
| ISDB-T Standard | Fully ISDB-T Compliant;support one seg/Full seg |
| FFT Size | 2K to 8K FFT Size |
| Support Bandwidth | 6M/7M/8M |
| Power | USB2.0 |
| RF interface | 2 RF Connector |
| Environment | Operation temperature:0~ +40℃, 10%≤Relative humidity≤90% |
| Support OS | Android 6.0 and above |
