Description
HD HDMI Video Capture Card with PCI-Express interface
HDCap X5156 is the 1080P60 capture card with PCIe x1 interface. It supports HDMI full HD 1080P60 and 4KP30 input, simply slide it into PCI-E X1 slot on your motherboard and twist one small screw to secure. After this, connect an HDMI cable to the “IN” port to whichever console you’d like to record from, and connect another HDMI cable to the “OUT” port so you can view it on your monitor or television.
Superb Software and OS Compatibility
UVC standard, Plug and Play, No Driver Required
- Support Windows, Linux, macOS and other main OS. Users can choose their favorite OS.
- Record and live stream games with 3rd party software, such as OBS Studio, Adobe Flash Media Live, VLC, etc.
- Compatible with most third party software Skype, Facebook Live, YouTube Live, LiveStream, UStream, Dacast, Wowza Cloud. It allows you to upload them to YouTube or Facebook for family and friends to enjoy too.
Capture and Streaming Products Comparison
| Interface | PCIe x1 |
|---|---|
| UVC Supported (Driver-Free) |
Yes |
| Video input | HDMI |
| Audio input | HDMI input and mirophone |
| Video loop through | HDMI |
| Supported video source | Blueray DVD, WiiU, Xbox 360, Xbox One, Ps4, HDMI PVR, Armarium… |
| Appliction | Video conference, Gaming, Tele-medicin, Stream media etc. |
| Support OS | Windows 7/8/8.1/10（32/64Bits）, OS X 10.9 and later, Linux, Android |
| Supported API | Windows:DirectShow, DirectSound, OS X:QuickTime, Linux, V4L2, ALSA |
| Support Software | Windows/Linux: OBS Studio; Windows Media Encoder; Adobe Flash Media Live Encoder; Real Producer Plus; VLC; Wirecast ; Xsplit Broadcaster; vMix; Potplayer Mac (Mac OS X): OBS Studio; QuickTime Broadcaster; Adobe Flash Media Live Encoder; VLC; Wirecast; Xsplit Broadcaster |
| Input | 640 x 360, 640 x 480, 720 x 480, 720 x 480, 720 x 576 , 768 x 576, 800 x 600, 856 x 480, 960 x 540, 1024 x 576, 1024 x 768, 1280 x 720, 1280 x 800, 1280 x 960, 1280 x 1024, 1368 x 768, 1440 x 900, 1600 x 1200, 1680 x 1050, 1920 x 1080, 1920 x 1200, 3840×2160; Frame rate: 25/29.97/30/50/59.94/60 /4K30fps |
| Capture | 640 x 360, 640 x 480, 720 x 480, 720 x 480, 720 x 576 , 768 x 576, 800 x 600, 856 x 480, 960 x 540, 1024 x 576, 1024 x 768, 1280 x 720, 1280 x 800, 1280 x 960, 1280 x 1024, 1368 x 768, 1440 x 900, 1600 x 1200, 1680 x 1050, 1920 x 1080, 1920 x 1200; Frame rate: 25/29.97/30/50/59.94/60 fps |
| Size | 121.3*102*18.9mm |
| Power | ≤2.5W |
| Package Contents | 1 X HDCap X5156, 1 X HDMI cable, 1 X User Manual |
