Description
Geniatech GTW361 IoT Gateways offer multi-protocol support, including RS485/RS232/CAN serial ports, network ports, and 4G/WiFi interfaces, ensuring seamless adaptation to diverse devices. With edge computing capabilities, they process and analyze data locally for faster decision-making. Integrating advanced technologies, these gateways deliver superior connectivity, security, and efficiency, bridging devices and systems to streamline operations for future-ready industries.
Specification
| General | Model: GTW361 System: Linux/Yocto CPU: NXP i.MX6ULL Core: Single ARM Cortex-A7 792MHz ~ 900MHz RAM: 512MB DDR + 8GB EMMC |
|---|---|
| Network | • 2G/3G/4G/LTE: LTE Cat4 for EU, LTE Cat4 for AU, LTE Cat4 for US (Optional) • Built-in WiFi: 802.11 a/b/g/n • Ethernet port(LAN): 2*RJ45 10/100Mbps LAN • PoE: IEEE802.3af standard, PoE PD with TVS protection (optional) |
| Power Adapter | • Supply voltage: DC12V 1.2A • Battery voltage: 3.7V 1000mAH ~ 5000mAH (optional) • Energy Within 5W (for reference only) • RTC battery: 3V 5mA charging type |
| I/O interface |
• USB x 1 • RS232 x 1 • RS485 x 2 • CAN x 1 • ZigBee 3.0 (optional) • Bluetooth/BLE 5.0 (optional) • LoRa: LoRaWAN communication specification (optional) |
| Extended interface | • LEDs: NET,Power,Battery,LoRa • SIM Slot: Micro SIM Card • GTIoT: 2*5P 1.27 socket (Internal port) • Debug: 4P 2.0 ranking (Internal port) • Extended interface UART: 6P 2.0 ranking(Internal interface) • Button: Reset |
| Control interface | • DI/DO: ±15KV(air) ±10KV(contact) • Relay: 2*3A 250VAC |
