OSM Size-L Module Solderable System-on-Module


+ -3 more
Clear selection
SKU: OSM Module Category:


Solderable and scalable embedded computer modules with new OSM standard

Geniatech SoM-3566-OSM board is an embedded core board developed according to the latest OSM (Open Standard Modules™) standard released by SGeT (Standardization Group for Embedded Technology e.V), It adopts with Rockchip’s RK3566 processor , up to 8GB (1/2/4/8G optional) LPDDR4 and 128GB(8/16/32/64/128GB) eMMC storage. It uses LGA package design, without connectors, can be directly soldered on the functional carrier board, which is more stable. Based on the design of OSM-L, it is small in size, low in power consumption, and has rich functional interfaces for expansion. It can be configured with a suitable development board according to the actual application. It can be flexibly used in audio-visual entertainment host, smart NVR, cloud terminal, IoT gateway, industrial control, edge computing, face gate, vehicle central control, commercial display equipment, AIoT and other application fields.

OSM Standard
Solder-on module LGA package
Small Form Factor, Low Cost Embedded Computer Module
Open Source Design
Rich hardware and software interfaces


Chipset Rockchip RK3566 (NXP iMX-8M-Mini / Renesas RZ-G2L optional)
OS Android 11 / Debian / BuildRoot etc
Processor CPU Quad-core 64-bit Cortex-A55processor, 22nm lithography process, main frequency can reach up to 1.8GHz
Supports OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1, Built-in high performance 2D acceleration hardware
NPU Integrated RKNN NPU AI accelerator, 1Tops@INT8
Supports one-click switching of Caffe/TensorFlow/TFLite/ONNX/PyTorch/Keras/Darknet
RAM 2GB LPDDR4 (1/4/8G optional)
ROM 16GB eMMC5.1 (8/32/64/128GB optional)
Network Ethernet RJ45, 1000M
WiFi Extend WiFi & Bluetooth via SDIO3.0
Display 1 x HDMI, 1 x eDP, 1 x LVDS, 1 x MIPI-DSI, 1 x MIPI CSI, Resolution up to 1920x1080
USB 1 x USB Host 3.0 , 1 x USB OTG 2.0, 2 x USB Host 2.0
Audio 1 x SPDIF, for audio output 1 x 8ch I²S /TDM, 1×8ch PDM, 1×2ch I²S/PCM>
Interface SDIO3.0, UART, I2C, FSPI, SPI, PWM, ADC, JTAG, GPIO, PCIe 2.1, CIF, I2S(Support 8-way digital microphone array input)
Dimensions 45 mm *45 mm (Size-L)
Adapter DC input voltage 5V
Temperature Consumer (0°C to 70°C Tj)
Industrial (-20°C to 85°C Tj)
RoHS and Reach compliant Yes

Additional information

Weight 0.5 kg


Form Factor
