Industrial-grade Fanless PC Box with Low Power and Embedded System
Geniatech APC820 is an industrial fanless PC box based on Rockchip RK3399 ARM based hexa-core CPU, features high performance and low power consumption, and a wealth of peripheral interfaces, supports multiple wireless and wired communication methods, Android 10 and Linux, which can adopted for many different applications and process your computing tasks more efficiently, which is ideal for industrial applications, space-constrained solutions, digital signage and more.
Display mode
APC820 is a high-performance player that supports multiple display interfaces, it is also equipped with HDMI 4KP30 input interface which can support up to 4K resolution.
Multiple functions and reliable performance
- Built-in independent watchdog to realize the function of 7*24H unattended, continuous and stable work
- Support digital tv tuner (optional)
- Support one Micro SIM card slot (optional), in order to connect 4G LTE for mobile digital signage solution.
- Android 10 / Linux — Dual system optional
Fanless Box PC Application
Digital Signage & Kiosk
Custom solutions for retail, healthcare, transportation, hospitality, etc.
Industrial Control & Monitoring
Machine control & monitor, Traffic control, Access control, Display control, etc
Smart Education
Video Conference
Specification
| Processor | RK3399 hexa-core 64 bit processor CPU: Cortex-A72 up to 1.8GHz + Quad-core Cortex-A53 up to 1.4GHz GPU: Mali-T860 GPU, support OpenGL ES1.1/2.0/3.0/3.1, OpenCL and DirectX 11.1 |
|---|---|
| OS Support | Android 10.0 / Linux optional |
| Memory | Onboard LPDDR4 2GB （4GB optional） |
| Storage | 16GB eMMC (8~128GB optional) 1 x Micro SD Slot (Max. 256GB) |
| Network | 1*RJ45 Gigabit LAN (LED) |
| Wireless | On-Board WiFi /BT module: 802.11 a/b/g/n/ac (2.4G/5.8G optional) + BT4.2 (Bluetooth 5.0 optional) 1 x Micro SIM slot (Support 4G 5G LTE optional) 1 x GTIOT: Support multiple optional wireless protocols(Z-WAVE / ZIGBEE / LoRa / LTE / GPS) |
| USB | 1 x Type C（Shared OTG） 1 x USB3.0 + 1x USB2.0 |
| Display Interface | 1x HDMI 2.0 input up to 4K Resolution (@30Hz) 1x HDMI 2.0 output up to 4K Resolution (@60Hz) |
| Tuner | Support a variety of digital TV reception : DVB-T2/T,ATSC optional |
| Watchdog Timer | Built-in |
| Cooling | Fanless |
| Enclosure Material | Aluminum |
| Other Feature | Support IR blaster (RS232 optional), Picture In Picture (PIP), MDM (Mobile Device Management) |
| Power Adapter | AC100 ～ 240V 50/60Hz DC 12.0V-2A |
| Dimension and Weight | Size: 136x136x35mm Net Weight: 312g |
| Package Contents | 1 x APC820, 1 X PSU, 1 X Remote, 1 X HDMI cable |
